XBO 900w/OFR Osram 69261 - This lamp is DISCONTINUED as of 2012

Cross Ref:?áUSE -?áXM900H/V ASL?á

CXL-900(NC)?á
XBO 900w OFR OSRAM
CXS900 (or) LTIX900W-H LTI
UXL-900-0 USHIO
ch900/V?á

Quantity Per Case: 1

XBO lamps are short-arc lamps in which light is generated by a discharge arc burning in pure high pressure Xenon gas between two electrodes. XBO lamps have a very high colour rendering index and extremely high luminance. For this reason they are used for cinema film projection, high-end video projectors and in light guide systems, e.g. for endoscopy.

XENON Foot Notes?á

• DHP = Digital High Performance (Barco?áProjectors) Long Life Version
• DHS = Digital High Performance Short (Barco?áProjectors)
• DTP?á = Digital Threaded Pin (Christie?áProjectors)
• DTS?á = Digital Threaded Super Performance (Christie?áProjectors)
• HPN = High Performance?áNEC
• HPS?á = High Performance?áSony
• S?á = Short

• C?á = Base with Cable
• H?á = Suitable for horizontal operation
• OFR = Ozone Free
• s (Operating Position) = Vertical, base down
• p (Operating Position) = Horizontal
  This lamp has positive pressure even when cold. Please read safety/warning instructions before using this lamp.
  Distance a is from end of base to the respective electrode tip (cold) - see lamp drawing.
  With vertical operating position: anode( ) on top.
